Eagle Eye Camera DB14
Description
Eagle Eye DB14 will be the recommended camera
for LPR applications. The camera features a large
1/1.8 inch sensor to provide better sensitivity in
varying conditions with different brightness levels.
Key features
• 1/1.8” Sony Sensor for superior low-light image quality
• Specialized AI ISP for better bitrate control and
image consistency
• Gen 3 IR with Smart Illumination (70m) to optimize
nighttime LPR performance
• 8-32m P-Iris Motorized Lens
• 4MP max resolutions up to 60fps
Warranty Information
Return and Refund Policy
Agent sales arguments
CAMERA
Pixels 4MP
Resolutions 2592×1520, 2304×1296, 1920×1080,
1280×720 @50/60 fps
Lens 8-32mm P-Iris Motorized Lens
LED Illumination Range Up to 70m (229ft)
Pan/Tilt/Rotation Range Pan: 0 ̊ ~ 355 ̊, Tilt: 0 ̊ ~ 80 ̊, Rotation: 0 ̊ ~ 360 ̊
Dynamic Range True WDR
Digital Noise Reduction 2D/3D DNR
Digital Image Stabilization Automatic
Applications Built to support EEN LPR applications, an excellent
choice for Gate or Street deployments for vehicle
speed up to 40 MPH or 60 KMPH
Image Sensor 1/1.8” Progressive Scan CMOS
Iris Fixed
Shutter Speed Auto/Manual, 1/5 to 1/100,000s
Min Illumination Color: 0.0025 Lux @ (F1.2, AGC ON);
B/W: 0 Lux with IR
DIGITAL CAPABILITIES
Video Compression H.265, H.264, and MJPEG
Image Settings: Rotation, saturation, brightness, contrast, sharpness
Corridor Mode Yes
SETUP
Eagle Eye Cloud VMS preconfigured with secure password, plug and play
Camera Settings Fully integrated with Eagle Eye Cloud VMS
Cyber Secure Eagle Eye Verified
INTERFACE
Ethernet 1 Ethernet (10/100 Base-T) RJ-45 Connector
Audio 1ch Input, 1ch Output, Built-in Mic, Built-in Speaker
PHYSICAL/POWER
Power DC12V (-15%~+20%)/POE (IEEE 802.3af)
Power Consumption Max 12 W
Operating Temperature -40°C to 60°C (-40°F to 140°F )
Operating Humidity Less than 90% RH
Ingress Protection IP66, IK10
Approvals CE/FCC
Dimensions 227.7 × 110 × 80 mm (8.96 × 4.33 × 3.15 inch)
Weight 0.82 kg (1.81 lb)
Housing Metal
