Eagle Eye Camera DX01
Description
8MP stitched 180° multi sensor (dual sensor)
with warm light illuminators
The DX01 is an 8MP 180° multi-sensor bullet camera
(stitched 2 x 5MP) with integrated warm light LEDs,
excellent for any application that requires extreme
fields of view at high resolution.
Key features
• 2 x 5MP sensors that create a stitched
180° view with 8MP resolution
• Only one subscription required
• 140 lumen white light illuminators
• Built-In speaker and microphone
• Audio and physical I/O
Warranty Information
Return and Refund Policy
Agent sales arguments
CAMERA
Pixels 8MP
Resolutions 4608×1728 @15fps, 2304x864 @ 15fps, 1536×576 @15fps
Lens Dual 2.8mm
LED Illumination Range Warm light distance up to 20 m (65.6ft)
Pan/Tilt/Rotation Range Pan: 0° ~ 355°/Tilt: 0° ~ 80°/Rotation: 0° ~ 360°
Dynamic Range True WDR
Digital Noise Reduction 2D/3D DNR
Digital Image Stabilization Automatic
Applications Best for outdoor applications that require perimeter
or large-area monitoring like sports fields, the sides of
large buildings, parking lots, roadways, etc.
Image Sensor Dual 1/2.8” Progressive Scan CMOS
Iris Fixed
Shutter Speed Auto/Manual, 1/5 ~ 1/20,000s
Min Illumination Color: 0.01 Lux @ (F1.6,AGC ON);
B/W: 0 Lux with Illuminator on
DIGITAL CAPABILITIES
Video Compression H.265, H.264, and MJPEG
Image Settings Rotation, saturation, brightness, contrast, sharpness
SETUP
Eagle Eye Cloud VMS Preconfigured with secure password, plug and play
Camera Settings Fully integrated with Eagle Eye Cloud VMS
Cyber Secure Eagle Eye Verified
INTERFACE
Ethernet 1 Ethernet (10/100 Base-T) RJ-45 Connector
Audio 1ch Input, 1ch Output, Built-in Mic, Built-in Speaker
PHYSICAL/POWER
Power DC12V (-15%~+20%)/POE (IEEE 802.3af)
Power Consumption Max 11.5 W
Operating Temperature -30°C to 60°C (-40°F to 131°F)
Operating Humidity Less than 90% RH
Ingress Protection IP66
Approvals CE/FCC
Dimensions 227.7 × 110 × 80 mm (8.96 × 4.33 × 3.15 inch)
Weight 0.82 kg (1.81 lb)
Housing: Metal
